Caddx Ratel 1200TVL 2.1mm FPV Camera w/ ND8 Filter (Yellow)

The Caddx Micro Ratel 2.1 w/ ND8 filter is equipped with a high-quality 1/1.18" inch starlight, HDR sensor, providing up to 0.0001 Sensitivity of lux. With the OSD menu, you can switch between PAL and NTSC video standards, or between 4:3 and 16:9 video formats.

The Caddx Ratel has a superb night vision effect and can be seen clearly under the faint light.

Features

• High quality 1/1.8" Inch starlight HDR sensor
• OSD menu
• Switch between PAL and NTSC video standards or between 4:3 and 16:9 video formats
• Ultra-low latency of 8ms

Specification

• Brand Name: Caddx Micro Ratel
• Item Name: Ratel
• Color: Yellow
• Lens: 2.1mm
• Image Sensor: 1/1.8" Inch starlight HDR sensor
• Horizontal Resolution: 1200TVL
• FOV: 180 Degree
• Min. Latency: 8ms
• TV System: NTSC & PAL (changeable)
• Image: 16:9 & 4:3 (changeable)
• WDR: Super WDR (HDR)
• Min. Illumination: Starlight
• Synchronization: Internal
• Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
• S/N Ratio: >60dB (AGC OFF)
• Video Output: CVBS
• Camera OSD: Separate OSD
• DNR: 3-DNR
• Language: ENG/FRANCE/RUS/SPA/PU/KOREA/CHN/JAPAN
• Day/Night: Auto/Color/B&W/EXT
• Dimensions: 19mm*19mm*19mm
• Wide Power Input: DC 5-40V
• Work Temperature: -20~+60°C
• Work Humidity: 20%~80%
• Weight: 8g (N.W.)/ 40.5g (G.W.)

How to

• Focusing your FPV Camera.
• All About Multirotor Drone FPV Cameras
• Getting the Right FPV Drone Camera Settings.

Video

Includes

• 1 x Camera
• 1 x 5D-OSD menu board
• 1 x 4pin FPV silicone cable A (extend into a 2pin joint for OSD board and a 3pin joint for FPV)
• 1 x FPV silicone cable B (2-pin port for both side)
• 1 x Internal hexagonal wrench
• 1 x Warranty card
