A DVR Created Purely for FPV

The internal DVR on FatShark Dominator Goggles is ‘ok’, but it doesn’t come close to the quality that PAL/NTSC can offer. Instead of the MJPEG compression used in the Dominator, the PowerPlay uses x264 (AVC) compression, with a much higher bit-rate. The 30fps frame rate of the Dominator is also doubled to 60fps, which is essential for capturing fluid race footage.

• Powers FatShark Goggles (with power switch)
• h264 Recording, at up to 60fps
• Built-in 6cm LCD display, showing recording + playback
• USB-C Charging
•  Accessories for Head, or Pocket Mounting

Note: 18500 Batteries NOT Included.

The Power Part…

PowerPlay’s Power section is a pair of two 18500, Li-ion cells, that can power a Dominator HDO + rapidFIRE + DVR for up to 3 hours *.
To recharge, either use the built-in USB-C port for up to 1.5A charging, or simply pop out the cells, and replace them with a freshly charged set.
Larger capacity 2040mAh cells are the same ones used in the FrSky X-Lite radios, so any decent FPV retailer will stock them.

18500 batteries no longer included.

Buy our recommended battery for the PowerPlay DVR.

Head Strap

The PowerPlay ships with a head-mounting accessory pack. A quick-release clip mounts on the rear of the standard goggle head strap, and the new included top-strap ensures a comfortable fit.

A short ‘Y’ cable connects to power, A/V, and the fan connector.
The rear-mounted DVR has the advantage of letting people standing behind you see what you, the pilot, is seeing.
A longer version of the cable is also supplied, for those who would rather keep their battery/DVR in a pocket, and keep weight off of the head.

Show off your Micro/Whoop footage

Quads that are extremely lightweight do not want the extra weight burden of an HD camera system. High-quality SD recordings of these amazing indoor flights are therefore of interest. PowerPlay delivers this quality.

PRODUCT SPECIFICATIONS

• Power: 2x 18500 Li-ion cells (without protection circuits)
• Power Switch: Yes… powers both the DVR and the Goggles
• Video File Format: h264 (AVC)
• Video File Resolution: 720×576 (PAL), 720×480 (NTSC)
• Video Data Rate: ~15Mbps (PAL), ~8Mbps (NTSC)
• Black Flashy: None

INCLUDED ACCESSORIES

• 1x PowerPlay DVR
• 1x Head Strap Clip
• 1x Over-head Strap
• 1x Replacement fan cover mounting kit w/Strap clip
• 1x Short DC/AV ‘Y’ cable for head-mounting use (incl. Fan Power)
• 1x Long DC/AV ‘Y’ cable for pocket use (incl. Fan Power)

Note: Batteries NOT Included

Buy our recommended battery for the PowerPlay DVR.
