SpeedyBee Mini V2 35A BLHeli_S 4-in-1 ESC - 20x20
SpeedyBee Mini V2 35A BLHeli_S 4-in-1 ESC - 20x20
In Stock
About this product
The SpeedyBee Mini V2 35A BLHeli_S 4-in-1 ESC - 20x20 is a testament to advanced engineering and thoughtful design, offering pilots a strong and powerful electronic speed controller for their FPV drones. With a focus on stability and strength, this ESC ensures your drone performs optimally under various flying conditions.
Note: (Insert any product notes here in Red BOLD Italic. Example: "First Shipment expected January 2022" or "Electronics are Not Included".)
VIDEO: Diatone Mamba H743 MK4 FC & 128K ESC Unboxing
Features
- Six-layer 2oz PCB combined with an optimized circuit design results in a stable and strong current output.
- Four-channel continuous 140A output capability for up to 30 seconds, delivering power when you need it.
- Uses Japanese TDK filtering SMT capacitors and an onboard TVS protective diode to enhance your flight experience.
- Successfully passed rigorous pressure testing with various 5-inch freestyle and racing drones.
- Demonstrates its powerful capability to drive any 2-4 inch and lightweight 5-inch drones with ease.
USE BULLETED FEATURE HERE IN BOLD CAPS.
Add additional feature descriptions here to describe the above.
USE BULLETED FEATURE HERE IN BOLD CAPS.
Add additional feature descriptions here to describe the above.
Specifications
- Firmware: BLHeli_S J-H-40
- Continuous Current: 35A * 4
- Burst Current: 45A (5seconds)
- ESC Protocol: DSHOT300/600
- Power Input: 3-6S LiPo
- Power Output: VBAT (Battery voltage, used to power the flight controller)
- Current Sensor: Support (Scale=250 Offset=-500)
- ESC Telemetry: Not supported
- Mounting: 20 x 20mm ø3.5mm hole size, compatible with M2 and M3 screws/Silicone grommets
- Dimension: 35 * 35 * 5.5mm
- Weight: 7.2g
IMPORTANT NOTES
- Insert important warnings or notes here. Example: "Do not overheat." or "Always use the included charger for best performance."
Recommended (Not Included)
- (Insert recommended products here. Example: "Battery: Lumenier 10000mAh 6s 25c Lipo Battery")
Links
- (Insert links such as manuals, firmware, etc)
Includes
- 1x SpeedyBee 35A BLHeli_S Mini V2 4-in-1 ESC
Featured Videos
ADD VIDEO TITLE HERE IN BOLD CAPS
ADD VIDEO TITLE HERE IN BOLD CAPS
More Information
SKU | 21077 |
---|---|
UPC (GTIN) | 724376355884 |
Manufacturer | SpeedyBee |
NDAA Compliant | No |
Mounting Pattern | 20x20mm |
Item Returns | This item can be returned |
