Skystars 4-in-1 3-6S 30x30 ESC - BLHeli_S KO55II 55A
$54.99
In Stock
Only left for same day shipping. Order now!
Skystars 4-in-1 3-6S 30x30 ESC - BLHeli_S KO55II 55A
The Skystars KO55II BLHeli_S 4-in-1 ESC has a 6-layer design and over-current capabilities. With BLHeli_S firmware, this ESC is a cost-effective solution for your quad.
About this product
The Skystars KO55II BLHeli_S 4-in-1 ESC has a 6-layer design and over-current capabilities. With BLHeli_S firmware, this ESC is a cost-effective solution for your quad.
Features
- Supports telemetry functions (including Voltage, RPMS, & Current)
- Toshiba standard 40V 5x6 Mosfet & electronics
- Lead-free SMT Processing technology
- ESC Onboard Current Sensor
- Over-Current Capabilities
- Supports 6S Batteries
- 6-layer Layout Design
- BLHeli_S Firmware
Specifications
- Dimensions: 41x46mm
- Mounting Holes: 30.5x30.5mm/¦µ3mm
- Weight:13.3g
- Supports: 3-6S Lipo input
- Firmware: BB21 MCU, 48Mhz Runs BLHELI 16.X Firmware
- Current sensor: YES
- BEC: NO
- Supports: DShot DShot150/300/600/MultiShot/ OneShot etc.
- Target: Q-H-30 BLS 16.7
- BLHeliSuite download
Includes
- 1x Skystars BLHeli_S 4-in-1 3-6S 30x30 ESC (KO55II - 55A)
- 1x 35v 560uf Capacitor
- 4x Rubber Grommet
- 1x Wire Harness
- 1x XT60 Cable
More Information
| SKU | 15966 |
|---|---|
| UPC (GTIN) | 736952011411 |
| Manufacturer | SkyStars |
| Country of Manufacture | China |
| NDAA Compliant | No |
| Mounting Pattern | 30.5x30.5mm |
| Amps | 55 Amps |
| Voltage | 3-6 Cell (11.1v-22.2v) |
| Number of ESC's | 4 ESC's in 1 |
