Diatone Mamba F722 Mini 20x20 Flight Controller

More Views

Diatone Mamba F722 Mini 20x20 Flight Controller
Diatone's Mamba series gives racers an edge in competition. The latest F7 processing technology means you can focus on flying, not on the limits of your equipment, even in a 20x20 form factor FC.
Back Ordered - Ships When Available
$33.99
OR
Description

Note: The STM32F722 generates much heat, please leave at least 5mm on both sides of the FC to give good air circulation.

Diatone's Mamba series gives racers an edge in competition. The latest F7 processing technology means you can focus on flying, not on the limits of your equipment, even in a 20x20 form factor FC.

With a wide range of setup options and features, you can configure your stack however you'd like.

30x30 version here.

Specifications

F722 Mini Flight Controller

  • MCU: 216MHz STM32F722RET6 32BIT
  • IMU: MPU6000
  • Baro: No
  • OSD: BF OSD
  • Blackbox: 16M Flash Memory
  • Uarts: 6Set
  • ESC Protocol: Dshot300/600/1200
  • ESC Telemetry: RX2
  • LED: Blue&Orange for FC Status, White 5V, Red 3.3V
  • WS2812 LED Control: BF LED Control
  • Smartaudio: Yes
  • RSSI: Yes
  • Buzz: Yes
  • Input: 2~6S Lipo (8.4~25V)
  • VTS Protection: Yes
  • BEC: 5V 2A (Max 3A)

Other

Physical

  • Mounting: 20×20mm, Φ2
  • Weight: 3.9gg total

Includes

  • 1x Diatone Mamba F722 Mini 20x20 Flight Controller
Additional Information
SKU 10577
Manufacturer Diatone
UPC (GTIN) 032733830081
