SpeedyBee F4 AIO Flight Controller w/ Bluetooth
This game-changing F4 flight controller allows you to configure and tune your Betaflight settings right from your phone via the SpeedyBee App!

About this product

The SpeedyBee F4 AIO Flight Controller is one of the first flight controllers ever to have Bluetooth functionality built-in. This game-changing feature allows you to configure and tune your Betaflight settings right from your phone via the SpeedyBee App! Other features include a built-in LC filter to clean up your video image, as well as an integrated PDB to power some external devices.

Note: You will still need a computer to flash firmware and configure your ESCs.

Specifications

MCU STM32F405
IMU MPU6000
OSD BetaFlight OSD w/ AT7456E chip
BLE Module Inner connect to UART5 for remote setting with Speedy Bee App or other similar apps
BlackBox 2MB onboard dataflash
Current Sensor 200A(Scale 302)
Power input 3s - 6s Lipo
Power output 4.5V * 1 , 3.3V * 1, 5V * 3 , 9V * 1
Cam And VTX power output Built-in LC-Filter for 5V and 9V
ESC power output 4 * VCC output
UART UART Pads * 3(UART1, UART3, UART4)
UART2 for Receiver Built in inverter of RX2 for SBUS input through SBUS pad, RX2 pad used for PPM, DSM2, DSMX, IBUS
RSSI input RSSI input solder pad
I2C Used for external GPS, Barometer module
Buzzer Buz- and 5V pad used for 5V Buzzer
ESC signal s1 - s7
LED pin Used for WS2812 LED
Boot button Used to easy enter DFU mode
Weight ≈8.8g
Dimension 36*39*7mm

Includes

  • SpeedyBee F4 AIO Flight controller * 1
  • M3*3+3 Nylon column * 6
  • M3 Nylon nut * 6
  • M3 Anti-vibration Gasket * 6
  • Rubycon 35V 470uf capacitor * 1
  • Manual * 1

Downloads

SpeedyBee App



More Information

SKU 8966
Manufacturer SpeedyBee
Mounting Pattern N/A
NDAA Compliant No
