SpeedyBee BT Nano 3 Wireless FC + ESC Configuration

SpeedyBee BT Nano 3 Wireless FC + ESC Configuration

In Stock

Only left for same day shipping. Order now!
Earn
SpeedyBee BT Nano 3 Wireless FC + ESC Configuration
Eliminate wire constraints and complicated driver installations with the SpeedyBee BT Nano 3 Wireless FC + ESC Configuration.

About this product

Eliminate wire constraints and complicated driver installations with the SpeedyBee BT Nano 3 Wireless FC + ESC Configuration. Supports the SpeedyBee App for wireless FC & ESC full configuration. The nano-size SpeedyBee BT Nano 3 Configuration features password protection and its Bluetooth automatically turns off when not in use to avoid interference.

Note: (Insert any product notes here in Red BOLD Italic. Example: "First Shipment expected January 2022" or "Electronics are Not Included".)

VIDEO: (Insert Video Title here in Bold)

Features

  • Wireless FC + ESC Configuration
  • Bluetooth automatically turns off
  • SpeedyBee App connectivity
  • Password protection
  • Nano-size
SpeedyBee BT Nano 3 Wireless FC + ESC Configuration InfographicSpeedyBee BT Nano 3 Wireless FC + ESC Configuration Infographic

USE BULLETED FEATURE HERE IN BOLD CAPS.

Add additional feature descriptions here to describe the above.

USE BULLETED FEATURE HERE IN BOLD CAPS.

Add additional feature descriptions here to describe the above.

Specifications

  • Bluetooth Automatically Turns Off: Enabled by default, the module will automatically detect the armed/ disarmed status of the FC. During the drone's flight, the Bluetooth function will be disabled to prevent other wireless devices from being interfered with by the Bluetooth signal. Operating Voltage: 5V
  • BT Switch Pad: The Bluetooth function will be disabled when it receives a Low signal. In the BT Switch section of the manual, you can learn about the detailed instructions
  • WiFi: Supports. It will be turned on automatically only when upgrading the module's firmware.
  • Power Indicator: Solid Red: Indicates that the module is powered.
  • Working Current: MAX~87mA(5V)
  • Bluetooth Low Energy: Supports
  • Communication Port: UART
  • Size: 14*11*0.8mm
  • Baudrate: 115200
  • Weight: 5g

Working Status Indicator

  • Flashing white: Indicates that the UART communication with FC is abnormal, please check whether the wiring and settings are correct.
  • Solid White: Indicates that the communication with FC is normal, you can use the App for wireless parameter adjustment
  • Flashing green: Indicates that the wireless signal is being connected
  • Solid Green: Indicates that the connection with the App has been successful

IMPORTANT NOTES

  • Insert important warnings or notes here. Example: "Do not overheat." or "Always use the included charger for best performance."

Recommended (Not Included)

Links

  •   (Insert links such as manuals, firmware, etc)

Includes

  • 1x SpeedyBee BT Nano 3 Wireless FC + ESC Configuration
  • 1x 29 AWG 19cable 75mm for BT Switch pad soldering
  • 2x 3M double-sided tape 14mmx30mm
  • 1x Heatshrink tube 18mm diameter

Featured Videos

ADD VIDEO TITLE HERE IN BOLD CAPS

ADD VIDEO TITLE HERE IN BOLD CAPS



More Information

SKU 19993
UPC (GTIN) 724376348022
Manufacturer SpeedyBee
NDAA Compliant No
Item Returns This item can be returned
