iFlight Nazgul Evoque F5 V3 BNF Drone HD w/ DJI O4 Pro + GPS

Every upgrade of the iFlight Nazgul Evoque F5 V3 BNF is engineered to elevate your flight experience to new heights. Featuring six core enhancements that redefine versatility and performance for drone enthusiasts. At its core, the innovative switchable DC/X-frame design stands out as a game-changer—seamlessly adapting to every flight scenario you demand. Opt for the DC geometry when capturing stunning cinematic shots, ensuring zero propeller obstruction for crystal-clear footage, or switch to the agile X geometry to unlock dynamic, high-speed freestyle maneuvers, making it a versatile companion for both creative filming and adrenaline-fueled flights.

• 4K Stabilized Video with a 155° Ultra-Wide Angle
• O4 Video Transmission – Enhanced Perception
• Latest Nazgul Frame for Maximum Protection
• Front-Mounted O4 Design
• Smooth and Powerful XING2 Motors

DC / X DUAL GEOMETRY FLEXIBLE SWITCHING

The innovative switchable DC/X-frame design offers unparalleled versatility. Whether you prefer the DC geometry for cinematic shots with no prop in view, or switch to the agile X geometry for dynamic freestyle maneuvers, Nazgul Evoque F5 V3 adapts to all flight scenarios.

BORG MINI STACK ENHANCED SAFETY AND STABILITY

Integrated anti-spark Filter, 65A burst current, dual independent BEC power supply, and built-in polymer capacitor further enhance safety and stability.

FRONT-MOUNTED AIR UNIT DESIGN

Upgraded front-mounted air unit design reduces interference. Improved assembly process with cleaner and more organized wiring, eliminating tangled cables and reducing the risk of malfunctions caused by wiring issues.

UPGRADED APPEARANCE STYLE MEETS PERFORMANCE

Innovative Fin-Shaped Cooling Channel significantly enhances heat dissipation. Even in hot weather, it quickly disperses heat to ensure stable flight performance.

REFINED INJECTION-MOLDED CONSTRUCTION UPGRADED QUALITY

Upgraded from TPU printed parts to full injection-molded components, delivering superior material integrity and refined tactile smoothness.

FLAGSHIP RECORDING CAPABILITY EQUIPPED WITH DJI O4 AIR UNIT PRO

Upgraded with a 1/1.3-inch image sensor, delivers remarkable performance in low-light and night environments. Capture low-altitude, high-speed flight footage in 4K resolution with an ultra-wide 155° FOV. Experience the immersive visual impact of flight like never before, with crisp 4K output that effortlessly meets your creative needs.

iFLIGHT NAZGUL EVOQUE F5 V3 BNF DRONE

• Max Hover Time: Approx. 7.5 mins (no load, with 6S 1480mAh battery)
• Operating Temperature Range: -10° to 40° C (14° to 104° F)
• Takeoff Weight: Approx. 695 ± 10 g (with 1480mAh battery)
• Dimensions (L × W × H): 190 × 136 × 36 ± 2 mm
• ESC: BLITZ Mini E55 4-IN-1 2-6S 55A ESC
• Video Transmission: DJI O4 Air Unit Pro
• FC: BLITZ Mini F722 Flight Controller
• Max Wind Speed Resistance: Level 7
• Maximum Takeoff Altitude: 3,200 m
• MCU: STM32F722RET6
• Gyro: ICM42688
• Barometer: SPA06-003
• GNSS： GPS+SBAS+Galileo+QZSS+Glonass
• Motor: XING2 2207 1750KV Motors
• Propellers: Nazgul F5 Propellers
• Frame Wheelbase: 223 ± 2 mm
• Max Flight Distance: 5 km
• Antennas: Dual Antennas
• Max Speed: 190 km/h
• Weight: 436 ± 5g

VIDEO TRANSMISSION

• Product Name: DJI O4 Air Unit Pro
• Image Sensor: 1/1.3-inch
• Lens: FOV: 155°
• ISO: 100-25600
• Video Resolution: 1080p/100fps H.265
• Video Format: MP4, Max Video Bitrate: 130Mbps
• Color Mode: Normal Mode/D-Log M
• Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)
• Live View Quality: 1080P@100fps
• Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz
• Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))
• Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
• Communication Bandwidth: Max 60 MHz
• Antenna: Dual antennas
• Built-in Storage: 4GB
• Supported SD cards: microSD (up to 512GB)
• Operating Temperature: -10° to 40° C
• Weight: Air Unit (camera module included): Approx. 32 g
• Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

• 1x iFlight Nazgul Evoque F5 V3 BNF Drone HD w/ DJI O4 Pro + GPS
• 2x Antennas
• 1x Battery pad
• 1x Propeller set
• 2x Battery strap
