NewBeeDrone AcroBee65 V3 BNF Tiny Whoop w/ BeeBrain BLV3

More Views

NewBeeDrone AcroBee65 V3 BNF Tiny Whoop w/ BeeBrain BLV3

Introducing... the NewBeeDrone AcroBee65 V3! All the quality and fun of NewBeeDrone micros, but now with updated features! The Acrobee65 is low-profile, durable, and fast - whether you are flying indoors or out. The V3 now comes with the improved BeeBrain BLV3 AIO Flight Controller and Gold Unibell 0802 18000KV Motors.

Backorder
$139.99
OR
Description

Introducing... the NewBeeDrone AcroBee65 V3All the quality and fun of NewBeeDrone micros, but now with updated features!

The Acrobee65 is low-profile, durable, and fast - whether you are flying indoors or out. The V3 now comes with the improved BeeBrain BLV3 AIO Flight Controller and Gold Unibell 0802 18000KV Motors. This version contains massive improvements to the performance of the built-in FrSky receiver and video transmitter. In addition, the ESC MOSFETs were upgraded to support the power demands of the micro toothpick drones. Soldering pads have been enlarged to enable custom builds allowing you to solder any motors of your choosing. Fly further than before with improved layout, removable antennas, and perfectly tuned RF impedance matching!

VIDEO: NewBeeDrone AcroBee65 V3

Features

  • VTX configurable on OSD (40 channels,) US versions will have some illegal channels locked.
  • Improved efficiency and board performance with the new VTX heatsink and ESC layout.
  • Customize your own flight preference with Betaflight and JESC Firmware.
  • 2 built-in LED's (programmable through Betaflight)
  • NewBeeDrone OSD Chips (Betaflight compatible)
  • Supports 120mW Transmission Power
  • Gold Unibell 0802 18000KV Motors
  • Voltage and Current sensor
  • Built-in FrSky SPI Reciever
  • VTX control through OSD
  • BeeBrain BL V3 AIO FC
  • Turtle Mode capable
  • Diversity RX
  • 2S capable

Receiver Improvements - 50% More Range

  • Optional wiring harness is available to install an external receiver (Crossfire, Ghost, etc)
  • Optimized SPI Receiver hardware to improve efficiency within the receiver.
  • Additional low noise amplifier to increase range.
  • Removable antennas.

Video Transmitter Improvements - 120mW

  • New heatsink and layout to increase heat dispersion and efficiency.
  • Transmitting power increased to 120mW from 25mW (V2)

Specifications

  • Receiver: Integrated True Diversity SPI Receiver with LNA+PA, FrSky compatible (optional external receiver compatible)
  • NewBeeDrone anti-reverse JST PH-2.0 Power Lead
  • ESC: 4 Channel 12A BLHeliS ESC with BB21 MCU
  • Camera: NewBeeDrone BeeEye FPV Camera
  • Motor center to motor center distance: 65mm
  • Propellers: 37mm Azi Tri-blade - 1mm shaft
  • Motors: Gold Unibell 0802 18000KV
  • VTX: Onboard Up to 120mW
  • Dimensions: 82x82x35mm
  • F4 STM32F411 Processor
  • Frame: Cockroach 65mm
  • Antenna: VTX
  • Weight: 23g

BeeBrain BLV3 AIO FC

  • UART2 TX and RX are free for the external receiver (un-inverted SBus signal only)
  • 4 channel 12A ESC with 48kHz JESC firmware (unlicensed)
  • Weight: 6 grams (including antennas and battery connector)
  • Size: Outer dimensions 29 x 29 x 7.6 mm
  • MCU: STM32F411 MCU
  • Holes: 25.5 x 25.5 mm
  • Battery input: 1–2S

Note: The default power mode is low (5mW). Set the power level to medium (50mW) before flying.

Recommended (Not Included)

Includes

  • 1x NewBeeDrone AcroBee65 V3 BNF Tiny Whoop w/ BeeBrain BLV3
  • Note: Battery Not Included
Additional Information
SKU 16896
Manufacturer NewBeeDrone
UPC (GTIN) 764613334616
