HGLRC F405 V1 2-8S Flight Controller - 30.5x30.5

This HGLRC F405 V1 flight controller features a high-precision ICM42688P gyroscope for smooth, stable handling, with optional support for the MPU6000. Its fully modular, plug-and-play design eliminates solder pads for a cleaner build. A built-in 16MB blackbox logs detailed flight data, while 8S support ensures fast response and consistent control for demanding freestyle and racing setups.

• Equipped with a high-performance ICM42688P gyroscope for precise, stable flight performance, with pads available for an MPU6000 gyro.
• Supports up to 8S high-voltage input with fast signal response, delivering smooth, consistent control for high-speed and aggressive flying.
• Fully modular, direct-connect layout with plug-and-play integration—no solder pads required.
• Built-in 16MB blackbox storage provides ample space for detailed flight data logging.

• Voltage: 7.4V-33.6V (2-8s)
• MCU: STM32F405
• GYRO: ICM42688P
• OSD: AT7456E
• Barometer: SPL06-001
• Black Box: 16MB
• UART: 5
• Flight Controller Firmware: HGLRCF405V2
• Dimensions: 36.3x36.3mm
• Mounting Holes: 30.5x30.5mm, M3
• Weight: 9.5g

• 1x 1x HGLRC F405 V1 2-8S Flight Controller
• 1x 30AWG 70mm, single-ended GH1.25-6P/single-ended SH1.0-7P
• 1x 30AWG, 60mm Single-End SH1.0-3P/Single-End SH1.25-3P
• 1x 30AWG, 70mm Dual-End SH1.0-4P Flex Cable
• 1x 30AWG 25mm Dual-End SH1.0-8P Flex Cable
• 1x 30AWG 140mm, double-ended SH1.0-6P
• 1x HGLRC  sticker
• 1x QR Code Card
• 4x Grommets
