CUAV SKYE 2 Airspeed Sensor

The CUAV SKYE 2 is the industry’s first intelligent airspeed meter with de-icing and drainage functionalities. It integrates an ARM M4 processor, a pitot tube, an airspeed sensor, a temperature and humidity sensor, and a dual temperature compensation system. SKYE 2 adopts DroneCAN protocol, supports open-source platforms such as ArduPilot, and is suitable for various Unmanned Systems models.

VIDEO: New product | SKYE 2 airspeed sensor

• Highly integrated design
• Intelligent de-icing and drainage
• New generation linear structure
• M4C intelligent, precise heating
• Shock resistance, low-temperature drift
• Adopts the DroneCAN protocol and supports the ArduPilot and PX4 platforms

• Processor: STM32F4
• Protocol: DroneCAN
• Airspeed sensor: SM5391
• Airspeed Sensor Options: PIX, V5+and X7 Series FC
• Power supply range: Default 18~68V
• Pitot tube heating power: 35W
• Temperature control type: Resistance heating
• Airspeed range: 0~106m/s
• Accuracy: ±1% FS
• Humidity measurement: 0–100%
• Temperature measurement: -20~125℃
• Measuring range: ±6895Pa
• Protection Level: IP54 (To be installed on request)
• Size: 101.9 × 28.2 × 29.9mm
• Weight: 24.38g

• 1x CUAV SKYE 2 Airspeed Sensor
• 1x SKYE 2 HV HUB
• 1x Airspeed Sensor Cable (HUB to SKYE)
• 1x CAN Data Cable (35mm)
• 1x XT30 Power Cable (20cm)
