Foxeer Datura 1507 FPV Motor - 2750KV/4150KV
The Foxeer Datura 1507 Motor stands out for its high performance, driven by a powerful N52H high-quality magnet that ensures surging power.

About this product

The Foxeer Datura 1507 Motor stands out for its high performance, driven by a powerful N52H high-quality magnet that ensures surging power. Available in two variants, 2750KV and 4150KV, it is designed to withstand extreme conditions with its military-grade 260°C radiation-resistant high-temperature winding. Crafted with a high-quality stator that adopts single crystal oxygen-free copper for its single wrap winding, the motor promises high efficiency.

(Insert Color Optioins here in Bold.)
Example: Choose Color: Red, White, or Blue.

Note: (Insert any product notes here in Red BOLD Italic.)

Example: "First Shipment is expected January 2022."

VIDEO: (Insert Video title here in BOLD)

Features

  • 2750KV/4150KV ratings available
  • Uses N52H high-quality magnet for surging power
  • Military Grade 260°C Radiation Resistant High Temperature Winding
  • High-quality stator
  • Adopt Single crystal oxygen-free copper single wrap winding, which results in high efficiency

USE BULLETED FEATURE HERE IN BOLD CAPS.

Add additional feature descriptions here to describe the above.

USE BULLETED FEATURE HERE IN BOLD CAPS.

Add additional feature descriptions here to describe the above.

Specifications

DATURA 1507-2750KV:

  • KV: 2750
  • Configuration: 9N12P
  • Stator Diameter: 15mm
  • Stator Length: 7mm
  • Shaft Diameter: 2mm
  • Motor Dimension (Diameter x Length): 20.7mm x 28.4mm
  • Weight: 16.5g (3cm Wire)
  • Idle Current(Io)@10V(A): 1.8A
  • No. of Cells (LiPo): 4-6S
  • Max Continuous Power(W)3S: 429
  • Internal Resistance: 110mΩ
  • Max. Efficiency Current: (3A-5A)>87%

DATURA 1507-4150KV:

  • KV: 4150
  • Configuration: 9N12P
  • Stator Diameter: 15mm
  • Stator Length: 7mm
  • Shaft Diameter: 2mm
  • Motor Dimension (Diameter x Length): 20.7mm x 28.4mm
  • Weight: 16.5g (3cm Wire)
  • Idle Current(Io)@10V(A): 3.4A
  • No. of Cells (LiPo): 3-4S
  • Max Continuous Power(W)3S: 348
  • Internal Resistance: 60mΩ
  • Max. Efficiency Current: (5-8)>86%

IMPORTANT NOTES

  • Insert important warnings or notes here. Example: "Do not overheat." or "Always use the included charger for best performance."

Recommended (Not Included)

Links

  •   (Insert links such as manuals, firmware, etc)

Includes

  • 1x Foxeer Datura 1507 Motor
  • 1x Hardware Set

Featured Videos

ADD VIDEO TITLE HERE IN BOLD CAPS

ADD VIDEO TITLE HERE IN BOLD CAPS



More Information

SKU 21418
Manufacturer Foxeer
NDAA Compliant No
Popo Compatible No
Item Returns This item can be returned
