Flywoo ROBO 1002 Motor - 15500KV/23500KV
Flywoo ROBO 1002 Motor - 15500KV/23500KV
$12.99
Select options for stock status
Only left for same day shipping. Order now!
Flywoo ROBO 1002 Motor - 15500KV/23500KV
The Flywoo ROBO 1002 is a lightweight, smooth, and powerful motor made for 1-2S drones.
About this product
The Flywoo ROBO 1002 is a lightweight, smooth, and powerful motor made for 1-2S drones.
Note: (Insert any product notes here in Red BOLD Italic. Example: "First Shipment expected January 2022" or "Electronics are Not Included".)
VIDEO: (Insert Video Title here in Bold)
Features
- 1-2S LiPo compatibility
- 2.4g in weight
- 1002 Stator
USE BULLETED FEATURE HERE IN BOLD CAPS.
Add additional feature descriptions here to describe the above.
USE BULLETED FEATURE HERE IN BOLD CAPS.
Add additional feature descriptions here to describe the above.
Specifications
15500KV
- Motor Dimension(Dia.*Len):Φ13.5*7.75mm
- Max.Efficiency Current:(1-3A)>84%
- Max Continuous Power(W)3S:67
- Internal Resistance:165mΩ
- Idle current(5)@5V(A):0.8
- Weight(g):2.4(5cm wire)
- No.of Cells(Lipo):1~2S
- Shaft Diameter:1.5mm
- Max Current(3S):10A
- Stator Diamter:10mm
- Configuration: 9N12P
- Stator Length:2mm
23500KV
- Motor Dimension(Dia.*Len):Φ13.5*7.75mm
- Max.Efficiency Current:(2-4A)>84%
- Max Continuous Power(W)3S:52
- Internal Resistance:70mΩ
- Idle current(5)@5V(A):1.5
- Max Current(3S):14.8A
- Weight(g):2.4(5cm wire)
- Shaft Diameter:1.5mm
- Stator Diamter:10mm
- Configuration: 9N12P
- No.of Cells(Lipo):1S
- Stator Length:2mm
IMPORTANT NOTES
- Insert important warnings or notes here. Example: "Do not overheat." or "Always use the included charger for best performance."
Recommended (Not Included)
- (Insert recommended products here. Example: "Propellers: HQProp 8X5 2-Blade Polycarbonate Propellers (Set of 4) - Light Gray")
Links
- (Insert links such as manuals, firmware, etc)
Includes
- 1x Flywoo ROBO 1002 Motor (15500KV or 23500KV)
- 1x M1.4*3 Screws Set
Featured Videos
ADD VIDEO TITLE HERE IN BOLD CAPS
ADD VIDEO TITLE HERE IN BOLD CAPS
More Information
SKU | 19537 |
---|---|
Manufacturer | Flywoo |
NDAA Compliant | No |
Popo Compatible | No |
Item Returns | This item can be returned |
