Cobra CP2814-2350KV Brushless Motor (Black)
The Cobra CP2814-2350KV Brushless Motor (Black).

About this product

As a family member of Cobra Champion series, the CP2814 also uses the highest ranked magnet as other Champion FPV racing motors do.

Specifications

  • Stator diameter: 28.0 mm (1.102 in)
  • Stator Thickness: 14.0 mm (0.551 in)
  • Number of Stator Slots: 12
  • Number of magnetic poles: 14
  • Motor wind: 10 Turn Delta
  • Motor Kv Value: 2350 RPM per volt
  • No Load Current (Io): 2.06 amps @ 10 volts
  • Motor Resistance (Rm) per phase: 0.036 Ohms
  • Motor Resistance (Rm) Phase to phase: 0.024 Ohms
  • Maximum Continuous Current: 48 Amps
  • Max Continuous Power (3-cell Li-Po): 530 Watts
  • Max Continuous Power (4-cell Li-Po): 700 watts
  • Motor Weight: 107 grams (3.77 oz.)
  • Outside Diameter: 35.0 mm (1.378 in.)
  • Shaft Diameter: 5.00 mm (0.197 in.)
  • Motor Body Length: 34.4 mm (1.354 in.)
  • Overall Shaft Length: 54.0 mm (2.126 in.)
  • Motor timing: 5-10 degrees
  • PWM Frequency: 8 KHz

Includes

  • 1x C2814-2350KV motor
  • 1x Heavy Duty 3mm Thick Cross Style Motor Mount
  • 4x M3x6mm Motor Mount Screws
  • 1x Bolt-On style threaded prop adapter with 4 screws
  • 1x Retaining Collar with Set Screw
  • 3x female 3.5mm bullet connectors
  • 3x pieces of heat-shrink tubing

More Information

SKU 7578
Manufacturer Cobra
Popo Compatible No
Item Returns This item can be returned
