Speedybee TX800 5.8GHz VTX
Out of Stock
About this product
The Speedybee TX800 is a small, yet powerful VTX. Capable of 800mW output all while fitting in a 20x20mm mounting pattern. The integrated heatsink keeps dangerous heat away from sensitive electronics.
Features
Specifications
- Frequency Channel: 5.8GHz 48CH
- Output Power: PIT/25mW/200mW/400mW/800mW
- Working Current: 5V@250~750mA
- Voltage out: 5V@max 250mA
- Voltage in: 3.7-5.5V
- Video input impedance: 75 Ohm
- Antenna Connector: MMCX
- Weight 5.6g: (without antenna)
- PCB Size: 28mm*28mm@20*20 M2
Includes
- 1x TX800 VTX
- 1x MMCX Antenna
- 1x MMCX to SMA Cable
- 1x 1.0mm 4pin Cable
FPV Regulatory Notice
The use and operation of this type of product in the USA and many other countries may require a license and some countries may forbid its use entirely. In the USA, you will need a "HAM" amateur radio license. Learn more about HAM licenses, and find a HAM license exam session in your area. It is your responsibility to ensure that the use of this product meets the requirements imposed by your government's rules and regulations for RF devices. Do not purchase this product if you are unsure of the government requirements or are not able to comply with them. GetFPV cannot be held responsible for your actions if you purchase and/or use this product in violation of your government's regulations. By agreeing to our terms and conditions during the check-out process, you also agree to have read and to understand this notice.
More Information
| SKU | 16867 |
|---|---|
| UPC (GTIN) | 764613336047 |
| Manufacturer | SpeedyBee |
| Country of Manufacture | China |
| NDAA Compliant | No |
| System Type | Analog |
| Max Output Power | 800mW |
| Mounting Pattern | 20x20mm |
| Antenna Connector / Length | MMCX |
| Tx Frequencies | 5.8GHz |
