Caddx Infra V2 FPV Camera

The Caddx Infra V2 FPV Camera delivers exceptional low-light performance with a black & white sensor. Powered by the new Infra V2 AI night vision enhancement algorithm, it boosts image clarity by more than 30% in low-light conditions. The upgraded AI processing chip also enables a more compact processor module, making the device thinner and lighter than ever.

Note: Infra V2 is an analog system and does not include the VTX.

• New V2 AI Image Enhancement
• High Resolution
• Reduced Size and Dimensions
• Black and White Sensor

• Using AI multi-frame algorithms to enhance dynamic range during night vision, effectively suppressing overexposure/underexposure in backlit scenes and preserving full image details. Compared to traditional color cameras, its sensitivity is much improved, allowing for better capture of object shapes and contours.
• The image sensor outputs in a native 4:3 aspect ratio, providing a full, uncropped image with sharp pixel clarity, letting you fully immerse in every flight moment with unmatched visual precision.
• Supports WDR, 100% satisfying the pursuit of detailed shooting in dark environments.
• Designed with a 131.6° ultra-wide-angle lens, the Infra V2 camera offers FPV pilots an expansive real-time view, improving situational awareness, enhancing image clarity, and capturing immersive, true-to-life visuals during every flight.
• Featuring a metal case, the lightweight design improves durability and heat dissipation. Utilizing a brand-new optical design to reduce lens size while ensuring the same light intake as Infra V1, making installation easier.

• Model: Caddx Infra V2
• Image sensor: 1/1.8 inch
• Pixel size: 8μm
• Horizontal resolution: 1500TVL
• Focal length: 2.8mm
• Aperture: F1.0
• FOV: 131.6°（D）
• Output format: CVBS PAL
• Frame rate: 50fps
• Image quality: Black & White
• Video interface: 1xPAL
• Supply Voltage: 9~24V
• Typical Power Consumption: <1.2W
• Aspect ratio: 4:3
• Operating temperature: -20℃~60℃
• Dimensions:

  • Camera: 20.5 x 20.5 x 26.9mm
  • AI Box: 34 x 34 x 13.2mm

IMPORTANT NOTES

• Infra V2 is an analog system and does not include the VTX.

• 1x Caddx Infra V2 FPV Camera
• 1x High-Frequency 470uf/35V Capacitor
• 1x Amass XT60 Connector
• 2x 12AWG 100mm Wire
• 2x 8-Pin SH1.0
