Flywoo GOKU F405 V2 Flight Controller (MPU6000)

The Flywoo GOKU F405 V2 (MPU6000) features 5 functional UARTS, BEC 5V 2A/9V 2A, 30.5X30.5 mounting holes and supports SBUS, IBus, DSMX/DSM2 and Crossfire receiver.

Features

• Support camera menu settings
• 5V&9V 2A BEC output
• Max voltage 50V input
• 5 functional UARTS
• Max 8 motor output
• Supports SBUS, iBUS, Spektrum & Crossfire Receivers
• DUAL camera switch
• VTX Power (9V) Switch

Specifications

• Input Voltage: 3-8s (Max 50V)
• MCU: STM32F405RGT6
• GYRO: MPU6000
• BARO: BMP280
• FLASH: 16M
• BEC: 5V 2A/9V 2A
• UARTs: 5 (UART1,3,4,5,6)
• Motor Outputs: 8
• Dual Camera Switch
• Supports Camera Menu Settings (Cam Control)
• Firmware: FLYWOOF405
• Dimensions: 36x39mm
• Mounting Hole: 30.5x30.5-3mm

Includes

• Flywoo GOKU F405 V2 Flight Controller - (MPU6000)
