Flywoo GOKU GM10 Pro V3 GPS Module w/ Compass
The Flywoo GOKU GM10 Pro V3 GPS Module with Compass and with more accurate positioning and faster Star Search using the latest M10050 GNSS Chip.
About this product
The Flywoo GOKU GM10 Pro V3 GPS Module with a compass and more accurate positioning and faster Star Search. It features the latest M10050 GNSS Chip. The Flywoo GOKU GM10 Pro V3 GPS Module features 72 searching channels and searches up to 30+ satellites for improved speed.
VIDEO: DJI O3 Air Unit / FLYWOO GM10 V3 GPS Series test
Features
- 1.0mm spacing between the 6pins patch seat
- GPS Module, Three Module Compass
- 72 searching channels
- Accurate positioning
- Up to 30+ satellites
- M10050 GNSS Chip
- Faster Star Search
USE BULLETED FEATURE HERE INÂ BOLD CAPS.
Add additional feature descriptions here to describe the above.
USE BULLETED FEATURE HERE INÂ BOLD CAPS.
Add additional feature descriptions here to describe the above.
Specifications
- Receiving Format: GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS
- Frequency: GPS L1, GLONASS L1, BeiDou B1, SBAS L1, Galileo E1
- Connector: 1.00mm spacing between the 6pins patch seat
- Chipset: M10050(Tenth Generation Chip)
- Default Protocol: GPS, Galileo, BeiDou
- Channels: 72 Searching Channel
- Dimension: 25mm x 25mm x 6mm
- Weight: 7.3g
- Reacquisition: -160dBm
- Tracking: -162dBm
DATA AND UPDATE RATE
- Support Rate: 4800bps to 921600bps,Default 115200bps
- Data Protocol: BF4.3.X(UBLOX)/BF4.2.X(NMEA)
- Data Level: TTL or RS-232, Default TTL level
Output frequency: 1Hz-10Hz,Default 10Hz
OPERATIONAL LIMITS
- Acceleration: Less than 4g
- Altitude: 50,000m Max
- Velocity: 500m/s Max
POWER CONSUMPTION
- Operating temp: -40 °C ~ +85°C
- Storage Temp: -40°C ~ +105°C
- VCC: DC Voltage:5V
INDICATOR
- PPS LED: yellow .PPS LED is not bright when GPS is not fixed, flashing when fixed
- The Module’s Pins: TX RX GND 5V SCL SDA
IMPORTANT NOTES
- The chip of GOKU GM10 V3 GPS is M1005. Only BF4.3x version firmware can use Ublox protocol. BF4.2x and earlier firmware can only use NMEA protocol But there is no difference in performance between the two protocols.
Recommended (Not Included)
- Â (Insert recommended products here. Example: "Battery: Lumenier 10000mAh 6s 25c Lipo Battery")
Links
- Â (Insert links such as manuals, firmware, etc)
Includes
- 1x Flywoo GOKU GM10 Pro V3 GPS Module w/ Compass
- 1x 150mm Cable
- 1x Copper Foil
