Dragonlink V3 Advanced Full Telemetry System

Dragonlink V3 Advanced Full Telemetry System

Dragonlink V3 Advanced Full Telemetry System
Want really long range? Dragonlink V3 Advanced is a Full Telemetry Long Range System (JR Version)

About this product

The Dragonlink system makes it easy to get everything you need for a 433MHz UHF long-range RC system.

The Dragonlink is a transmitter module that will hook up to your current RC transmitter and will result in flights that not only go further, but allow you to fly lower, and in high interference areas – like cities – without fear of glitches and loss of RC control.

This is a TOTALLY NEW design, not an update. Constructed using the best performing high quality componenets, latest and most advanced technology available. This system is built to outperform everything else on market and last for many years. It is not cheap, but it will be the best FPV investment you will make. Full Bidirectional Telemetry to 50 KM with stock antennas. Built in serial Radio Modem Works with Mission Planner / Droid Planner (Wish GPS installed) Built in Bluetooth for any android Smartphone or Tablet Fully configurable using PC software. Configuration via android device (in development) Adds up to 3 Channels to your RC system with switches and knobs on top of unit Lost plane finder - Simply see where it is on Smartphone Configurable, Multifunction Switches and Knobs Two Multicolor Status LED's for alarms, status, voltage, etc. Audible alarms (For Low Voltage in Copters, Low RSSI, Etc) Works with current Micro Receivers. Full Logging of flight, position, etc. Removable SD card. Spectrum Analyzer Super Fast update rate for Racers and obstacle flyers. Hassle free, no extra steps operation for those that want basic experience. Fully compatible with Existing Dragon Link Micro Receivers (Full Bidirectional) Future Compatibility (One Way) for V2 Receivers that have Next Generation Firmware on them. It is Dragon Link, it will outperform anything in existence.

The Dragon Link complete system is made in the USA, and FULLY GUARANTEED in the USA. The system includes everything you need for long range and high performance RC control, there is nothing additional to purchase. Just order the complete system, and chose the correct options above for your RC Transmitter connection cables and airplane antenna options. NOTE: The Dragon Link system is for RC control only, it does not transmit or affect video transmission in any way.

The Dragon Link Micro Receiver is tiny, and at 10 grams is very light, but it is NOT a " Micro Receiver " in performance !!! The Micro RX is a FULL RANGE, 12 Channel, full performance, full featured receiver. The Micro Receiver outputs PPM, Sbus, Standard PWM servo signals, and is fully compatible with ALL Copters, flight controllers, OSD's, Autopilots, and other FPV devices. The micro receiver is the best oerfirnugm most advanced RC receiver ever made !!! The micro receiver is plug and play, and will work perfectly right out of the box. If you do wish to connect it to your computer, just connect it with any standard Micro USB cable as you would have for your cellphone or camera, and you can access a vast amount of features built in. Features include: Fully configurable channel mapping, Spectrum Analyzer, Emergency Plane Locater Beacon, Built in Memory for Complete System logging, GPS input, and more. The really great thing about this receiver is that each output pin is assignable to any channel that you want. To use all 12 channels of the Micro receiver, Simply feed the PPM output to your flight controller or OSD, and assign the remaining pins of the receiver to higher channels and accessories, This way you can use all 12 channels though this small receiver, All flight controls though the PPM and free up the remaining output pins for servos and accessories. For complete information on this new receiver, download the PDF Manual & Configuration Software.

Dragonlink is a high quality system, made in the USA by experts in the field, and is fully guaranteed and supported.

View the Manufacturer's Website / Official Forum thread.


  • Transmitter Module Voltage: 5 - 18 Volts (2-4 cell LiPo)
  • Receiver Voltage: 5 - 9 Volts (UBEC or 2 cell LiPo)
  • Frequency: 433 MHZ - Frequency Hopping in ARS Band.
  • Typical Range: 40 KM Using Supplied Antennas


The Dragonlink System comes with everything you need for long range RC

  • 1x Long Range Transmitter Module
  • 1x Long Range Advanced Micro Receiver
  • 1x Genuine Nagoya Transmitter Antenna
  • 1x High Performance FPVPro Receiver Antenna
  • 1x Connection Cable for Transmitter Module
  • 1x Mounting Bracket for Transmitter Module
  • 2x Dragon Link Decals

FPV Regulatory Notice

The use and operation of this type of product in the USA and many other countries may require a license and some countries may forbid its use entirely. In the USA, you will need a "HAM" amateur radio license. Learn more about HAM licenses, and find a HAM license exam session in your area. It is your responsibility to ensure that the use of this product meets the requirements imposed by your government's rules and regulations for RF devices. Do not purchase this product if you are unsure of the government requirements or are not able to comply with them. GetFPV cannot be held responsible for your actions if you purchase and/or use this product in violation of your government's regulations. By agreeing to our terms and conditions during the check-out process, you also agree to have read and to understand this notice.

More Information

SKU 4975
Manufacturer DragonLabs
NDAA Compliant No
Item Returns This item can be returned
