JHEMCU AIO Board - GHF412 F411 FC + 12A 2-4S BLHeli_S ESC w/ Barometer

The JHEMCU GHF412 AIO features an F411 FC and a 12A ESC with Barometer. This is an ultra-light 5g brushless AIO flight controller!! This FC has a strong performance and can handle 12A of continuous current and up to 4S. Perfect for 3" builds or smaller with a 25.5x25.5 mounting pattern!

Features

• GHF412 FC
• Barometer
• 12A ESC

Specifications

GHF412 FLIGHT CONTROLLER

• Receiver: Support Frsky XM / XM + receiver / Futaba receiver / Flysky receiver / TBS Crossfire receiver / DSMX receiver
• OSD: Built-in BetaFlight OSD (OSD chip: AT7456E)
• Item Name: F4 Flight Controller AIO 12A 4IN1 ESC
• Support programmable LED such as WS2812
• MPU: MPU6000 (SPI connection)
• Mounting Pattern: 25.5x25.5mm
• CPU: STM32F411 (100MHZ)
• Built-in current sensor
• Firmware: JHEF411
• Size: 32.5x32.5mm
• Model: GHF412AIO
• Brand: JHEMCU
• Weight: 5g

12A ESC

• Supports: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
• Firmware: BLHELI_S (G_H_30_REV16_7.HEX)
• Motor connector: 1.25mm pin header connector
• Firmware: BLheli / BLHELI_S
• Continuous current: 12A
• Input voltage: 2-4S Lipo

Includes

• 1x JHEMCU AIO Board - GHF412 F411 FC + 12A 2-4S BLHeli_S ESC w/ Barometer
• 2x Power Cord  (18awg 1 black,1 red)
• 4x Rubber Shock Absorber
• 1x 470uf 35V Capacitor
• 1x XT30 Connector
