IBCrazy 5.8 GHz Bluebeam Classic Antenna (RHCP)

The antenna set that started the revolution and spawned copy after copy. The Bluebeam Line of Antennas were the first Circularly Polarized antennas made available to FPV pilots way back in 2011. The Bluebeam Classic is a throw back to the early Bluebeam Whip design with a stronger RG-402 Mil-Spec cable. While the lobes are run exposed on the Bluebeam Classics, the feed in the center of the antenna is encapsulated for protection of the solder joints.  This allows for the lobes to bend freely in a crash and be bent back into shape by the operator many times before needing a replacement antenna.

Specifications:

• Cloverleaf (3-Lobe)
• Skew-Planar Wheel (4-lobe)
• Gain: 1.4dbic
• Gain: 0.92dbic
• Axial Ratio: .61
• Axial ratio: .54
• Polarization: Right Hand Circular (RHCP)

Package includes:

• 1x Cloverleaf antenna
• 1x Skew-Planar Wheel antenna
• 2x RPSMA adapters
• 2x VAS finger wrenches
