Diatone Mamba Basic Stack - F405 Mini MK3.5 FC + F30 30A BLHeli_S Mini ESC

The Diatone Mamba F405 Mini MK3.5 30A Basic Stack brings BIG power all in a 20x20 mounting size! This stack can push 30A all while bringing you the latest features!

Features

• Gyro uses an independent Low Dropout Regulator (Low Dropout Regulator) and reduces ripple interference
• The standard flight controller (30.5×30.5) adds a spare pad
• Self-recovery insurance to the receiver's 5V power supply
• LED signal selection (when Mamba Led sys avaiable）
• Increased camera VCC power supply pad
• TVS instant high voltage protection 30V
• F405 models support F.prot
• BEC short circuit protection
• Super Big Soldering Pad
• Increased pad area

Updates

• When you connect the USB, the receiver and OSD settings can be saved
• The pad area of the Mini flight controller (20×20) increased by 140%
• Upgraded anti-interference cable
• Added I2C function
• Use TypeC

Specifications

MAMBA Basic F405MINI MK3.5 FC

• MCU: 168MHz STM32F405RGT6
• Blackbox: 16M Flash Memory
• Input: 2~6S Lipo (8.4~25.2V)
• BEC:3.3V 0.5A& 5V 2.5A
• ESC Soft: Dshot300/600
• MOUNTING: 20mm, M2
• LED Controller: BF LED
• TVS Protection: Yes
• GYRO: MPU6000
• Power Led: Yes
• Barometer: Yes
• Uarts: 5 Set
• RSSI: Yes
• Buzz: Yes
• OSD: Yes

MAMBA F30 MINI ESC

• CONTINUE CURRENT: 30A×4
• High-Frequency 470uF/35V ×1
• BURST CURRENT: 40A (10S)
• INPUT VOLTAGE: 3~5S Lipo
• Target：BLHeli_S CH40
• MOUNTING: 20mm, M2
• AMASS Original XT30
• SOFT: Dshot300/600
• TVS Protection: Yes
• BEC: No

Includes

• 1x MAMBA Stack Basic F405 Mini MK3.5 30A
• 2x 16AWG 60mm Cable
• 2x 8pin sh1.0
