The MultiView Duo is a micro, lightweight, camera switcher designed for high-performance FPV applications. Using either a PWM (“servo”) or Digital (“pinIO”) input, the MultiView Duo can switch between two cameras connected to a single VTX.
The onboard regulator features a 4.2-30v tolerant input, making it compatible with 5v regulated supplies, as well as batteries ranging from 2S to 6S. These input power rails are passed from the video output side through to the camera input side, providing power to the cameras and yielding a clean look when wired up. For those using 6S, quick disarms from full throttle can cause voltage spikes that exceed the recommended voltage for the MultiView. It is recommended for these situations that the MultiView is powered from a regulated supply.
The MultiView’s switching design minimizes transition time and adds zero additional latency to the video feed. Its miniature size (17 by 10 mm) makes it an ideal choice for mini quads and smaller wings, and its light weight (less than a gram) makes allows for consistent performance on high-speed models.
- Dimensions: 10 Mm X 17 Mm
- Weight: .9 Grams
- Inputs: 2 - PWM or Digital
- Voltage Input: 4.2 - 30 V
- Additional Information
SKU 9360 Manufacturer Bicks UPC (GTIN) 721248873422 Static Block No
