BETAFPV X-Knight 5" V2 Frame Kit

More Views

BETAFPV X-Knight 5" V2 Frame Kit

The BETAFPV X-Knight Carbon Fiber 5'' V2 Frame Kit comes with the motor mounting hole 12×12 for M2, which can fit for the brushless motors like 1606/1805 and is compatible with the F4 AIO 35A toothpick FC.

In Stock
$22.99
OR
Description

The BETAFPV X-Knight Carbon Fiber 5'' V2 Frame Kit comes with the motor mounting hole 12×12 for M2, which can fit for the brushless motors like 1606/1805. Made with T800 carbon material for durability, while maintaining minimal weight. Compatible with F4 AIO 35A toothpick FC and 1606, 1805 series 4-6S brushless motors!

Features

  • X-Knight 5’’ V2 frame is a lightweight 5inch assembled toothpick carbon fiber frame kit, which is perfect for the X-knight 5inch quadcopter. Comes with titanium alloy screws, weights only 26.44g/pc.
  • X-Knight 5inch V2 toothpick carbon fiber frame consists of 4 arms, top plate, and bottom plate. Product top plate with compression nuts for easy installation. Lightweight, super-stiff, but power and strong enough.
  • It is compatible with F4 AIO 35A toothpick FC and 1606, 1805 series 4-6S brushless motors.
  • X-Knight 5’’ V2 frame kit is made of T800 carbon fiber material with 200mm wheelbase, the thickness of the solid removable arm is 3.5mm, guaranteeing the flight power of Quadcopter.
  • Adopted the spraying process with an insulating effect on frame surface, effectively reducing the possibility of component damage caused by electric current.

Specifications

  • Material: T800 Carbon Fiber
  • Wheelbase: 200mm
  • Weight: 26.44g
  • Frame Height: 8mm
  • Top plate thickness: 1.5mm
  • Bottom plate thickness: 1.5mm
  • Arm thickness: 3.5mm
  • Battery protected plate thickness: 1.5mm
  • Motor mounting hole: 12 x 12
  • FC mounting hole: 26.5mm x 26.5mm

Recommended Parts (Not Included)

Includes

  • 1 x Top Plate
  • 1 x Bottom Plate
  • 4 x Arms
  • 1 x Battery Protected Plate
  • 8 x M2×8 Countersunk Screws
  • 4 x M2×10 Screws
  • 8 x M2 Nuts
  • 8 x M2*1.85 Nuts
  • 1 x Battery Strap
  • 2 x Anti-slip Battery Mats
  • 2 x 3mm Anti-impact Battery Mats
  • 2 x 5mm Anti-impact Battery Mats
Additional Information
SKU 13522
Manufacturer BETAFPV
UPC (GTIN) 751313216823
