Fat Shark 5.8GHZ 5G8RX 32ch Race Band Receiver Module for Dominators

In Stock
$30.00
OR

Quick Overview

The Fat Shark 5.8GHz 5G8RX 32ch Race Band Receiver Module provides 32 channels on the 5Ghz band. Fully race ready, this module is plug and play with FatShark Dominator goggles. Two dip switches on the front of the module allow you to select one of 4 bands, then you can select any of the 8 channels on your headset.

Fat Shark 5.8GHZ 5G8RX 32ch Race Band Receiver Module for Dominators

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

Installs directly into the Dominator goggle set to instantly give you 5.8ghz Raceband to go with your Vortex. Instantly add those channels you're missing in your Dominators that also suit all the Boscam A and E frequencies so now you can cover all the missing bands and channels with your goggles. Plug and play with Dominator goggles and opens access to that Raceband in the ImmersionRC Vortex. Based on the NexWaves RF NWM662JRX. Factory tested to -90dBm

Channels Supported:

DIP Switch Band Name CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
0-0 1 Fat Shark /IRC 5740 5760 5780 5800 5820 5840 5860 5880
0-1 2 Boscam E 5705 5685 5665 5645 5885 5905 5925 5945
1-0 3 Boscam A 5865 5845 5825 5805 5785 5765 5745 5725
1-1 4 RaceBand 5658 5695 5732 5769 5806 5843 5880 5917

Compatible with the 600mw 5.8Ghz Audio/Video Transmitter and also your ImmersionRC Vortex

Additional Information

SKU 2830
Manufacturer FatShark

FPV Regulatory Notice

The use and operation of this type of product in the USA and many other countries may require a license and some countries may forbid its use entirely. In the USA, you will need a "HAM" amateur radio license. Learn more about HAM licenses. It is your responsibility to ensure that the use of this product meets the requirements imposed by your government’s rules and regulations for RF devices. Do not purchase this product if you are unsure of the government requirements or are not able to comply with them. GetFPV cannot be held responsible for your actions if you purchase and/or use this product in violation of your government's regulations. By agreeing to our terms and conditions during the check-out process, you also agree to have read and to understand this notice.
