SpeedyBee F4 AIO Flight Controller w/ Bluetooth
This game-changing F4 flight controller allows you to configure and tune your Betaflight settings right from your phone via the SpeedyBee App!
About this product
The SpeedyBee F4 AIO Flight Controller is one of the first flight controllers ever to have Bluetooth functionality built-in. This game-changing feature allows you to configure and tune your Betaflight settings right from your phone via the SpeedyBee App! Other features include a built-in LC filter to clean up your video image, as well as an integrated PDB to power some external devices.
Note: You will still need a computer to flash firmware and configure your ESCs.
Specifications
| MCU | STM32F405 |
| IMU | MPU6000 |
| OSD | BetaFlight OSD w/ AT7456E chip |
| BLE Module | Inner connect to UART5 for remote setting with Speedy Bee App or other similar apps |
| BlackBox | 2MB onboard dataflash |
| Current Sensor | 200A(Scale 302) |
| Power input | 3s - 6s Lipo |
| Power output | 4.5V * 1 , 3.3V * 1, 5V * 3 , 9V * 1 |
| Cam And VTX power output | Built-in LC-Filter for 5V and 9V |
| ESC power output | 4 * VCC output |
| UART | UART Pads * 3(UART1, UART3, UART4) |
| UART2 for Receiver | Built in inverter of RX2 for SBUS input through SBUS pad, RX2 pad used for PPM, DSM2, DSMX, IBUS |
| RSSI input | RSSI input solder pad |
| I2C | Used for external GPS, Barometer module |
| Buzzer | Buz- and 5V pad used for 5V Buzzer |
| ESC signal | s1 - s7 |
| LED pin | Used for WS2812 LED |
| Boot button | Used to easy enter DFU mode |
| Weight | ≈8.8g |
| Dimension | 36*39*7mm |
Includes
- SpeedyBee F4 AIO Flight controller * 1
- M3*3+3 Nylon column * 6
- M3 Nylon nut * 6
- M3 Anti-vibration Gasket * 6
- Rubycon 35V 470uf capacitor * 1
- Manual * 1
Downloads
SpeedyBee App
- iOS 10.0+：iPhone4S, iPad 3rd Gen and later iOS App Store
- Android 4.3+: Google Play
- APK
